LIGHT SOURCE

● Light Source: Original PHILIPS 350W lamp(7500K)

● Ballest: Original PHILIPS

● Average Life Span: 1000~1500hours

POWER

● Input Voltage: AC90~240V, 50/60Hz

● Power Consumption: 500W/600W

OPTICAL SYSTEM

● Luminous Flux: 160000lumen@10m

● Beam Angle: 3°

● Focus: Motorized linear focus

● 1 Prism Wheel: 1pc 16-facet prism, bidirectionally rotating at variable speed(3-facet or 8-facet prism optional)

● Frost: 1pc frost filter, can achieve soft light effect

● Dimmer: 0~100% mechanical dimming, smooth without flicker

● Strobe: Independently strobe with double motors, 0.5~20 F.P.S, speed adjustable

● Lens: Use imported multilayer coating lens combination, the diameter of beam aperture is up to 160mm

● Projection Distance: Over 1000m with similar parallel light

MOVEMENT

● Pan and Tilt: Use high precision 3-phase motors for pan and tilt, accurate location, smoothly moving, automatic correction location

● Pan: 540°rotation, 8/16Bit adjustment

● Tilt: 270°rotation, 8/16Bit adjustment

COLOR SYSTEM

● 1 Color Wheel: 14pcs colors+open, half color and rainbow effect

GOBOS

● 1 Fixed Gobo Wheel: 17pcs fixed gobos+open, bidirectionally shaking & flowing at variable speed

CONTROL

● Control Mode: DMX512(wireless DMX512 can be customized), Auto Run, Sound Control, Master\Slave and Manual

● DMX Channels: 16/20CH

● Lamp Control: Control the lamp on/off via controller

PHYSICAL

● IP Grade: IP65

● DMX Connector: 3-pin waterproof signal in and out XLR

● Display: 2.8 inch colorful LCD screen, 180° inversion

● Power Cable: Waterproof power cable

MATERIAL

● Fixture Material: High hardness heat dissipation aluminum profile, use outdoor imported fine sand spraying technology, anti-uv treatment, anti-aging, high temperature, long service life

COOLING SYSTEM

● Cooling System: Use imported fans, the chip controls the fan speed, the original heat dissipation structure, cooperate with the radiator shell, guarantee the long time outdoor use

FEATURE

● Feature: It can be programmed independently via LCD display, master and slave lights are running synchronously without controller operation

WEIGHT & DIMENSION

● Fixture N.W.: 35KG

● Carton G.W.: 40KG

● Flight Case G.W.: 57KG

● Fixture Size: L400*W400*H730(mm)

● Carton Size: L650*W590*H920(mm)

● Flight Case Size: L550*W480*H970(mm)
